Finding a specific parts diagram for your 1980 Suzuki GS750 gas tank can be tricky. Unfortunately, there isn't a single, universally accessible online diagram readily available. However, this guide will equip you with the information and resources you need to successfully identify and source the parts you require.
Where to Find 1980 Suzuki GS750 Gas Tank Parts Diagrams
Your best bet for obtaining a detailed parts diagram is through these avenues:
-
Suzuki Motorcycle Dealerships: Your local Suzuki dealership will have access to the official Suzuki parts catalog, which includes exploded diagrams showing every component of the gas tank. They can look up the diagram using your motorcycle's VIN (Vehicle Identification Number). Be prepared to provide this information.
-
Online Motorcycle Parts Retailers: Many online retailers specializing in motorcycle parts (like BikeBandit, Partzilla, etc.) allow you to search for parts by motorcycle make, model, and year. While they might not always offer a full exploded diagram like the dealer's catalog, they typically offer detailed images and descriptions that can help you identify the part you need. Again, having your VIN handy is beneficial.
-
Microfiche Readers: Older parts catalogs were often distributed on microfiche. Some libraries or specialized motorcycle repair shops might still possess these. These require a microfiche reader to view the diagrams.
Understanding Gas Tank Components: What Parts Might You Need?
A gas tank, seemingly simple, actually comprises numerous parts. Knowing which part you need is crucial. Common issues and associated parts include:
- Gas Tank Petcock: This valve controls fuel flow to the carburetor. Issues like leaks or sticking can require replacement.
- Gas Tank Cap: A simple yet essential part; problems can range from a damaged seal to a broken locking mechanism.
- Gas Tank Straps/Mounts: These secure the tank to the motorcycle frame. Worn or broken straps can lead to tank instability.
- Gas Tank Rubber Grommets/Bushings: These are often overlooked, but worn grommets can cause leaks or rattling.
- Fuel Sender Unit (If Equipped): Older models might not have fuel gauges; however, if yours does, the sender unit is responsible for sending the fuel level signal to the gauge. Problems with this can lead to inaccurate readings or a non-functioning gauge.
- Gas Tank itself: In case of significant damage, you may need a replacement tank. This is the most significant expense.
How to Use a Parts Diagram Effectively
Once you locate a diagram, take your time to examine it carefully. Typically, parts are numbered, and a corresponding parts list provides descriptions and part numbers. This allows you to identify and order the correct parts.
What if I can't find a diagram?
If you are struggling to find a suitable diagram, consider these alternatives:
- High-Resolution Photos: Take detailed pictures of your gas tank, highlighting the problematic areas. These photos can aid a mechanic or parts retailer in identifying the required components.
- Contacting Motorcycle Forums: Online forums dedicated to Suzuki motorcycles (or classic motorcycles in general) are invaluable resources. Experienced owners often share repair experiences and parts sourcing tips.
By following these steps, you'll greatly increase your chances of successfully finding and ordering the necessary parts for your 1980 Suzuki GS750 gas tank. Remember, patience and thorough research are key.
